Radiation injury

Radiation injury

Introduction

  • Ionising radiation
    • High-energy, short-wavelength, high-frequency with enough energy to remove an electron from an atom and generate charged particles
    • Alpha particles, beta particles, neutrons and sole energy waves that include x-rays and gamma rays
  • Alpha particles
    • Charge +2. 2 protons and 2 neutrons.
    • Penetrate a few centimetres in air. Shielded by paper and keratin layer of skin.
    • Must be ingested, inhaled or absorbed for injury
    • Source – Plutonium, uranium, radon
  • Beta particles
    • Charge -1. Penetrate 8mm into skin. Shielded by clothing.
    • Hazardous if internally deposited
    • Most radio-isotopes decay by beta followed by gamma emission
  • Positron
    • Charge +1. 8mm into skin. Shielded with lead, steel or concrete.
    • Interact with electrons to release photons of energy
    • Source: Medical tracers
  • Neutron
    • Charge 0
    • Variable penetration. Shieled by material with high hydrogen content e.g. heavy water
    • Source: Nuclear power plants, particle accelerators, weapons plants
  • Gamma and X-rays
    • Charge 0
    • Several cm into tissue
    • Shielded by concrete and lead
    • Most radio-isotopes decay by beta followed by gamma emission

ALLOWED DOSE

  • Background radiation is 6.2 mSv
  • Allowed 1mSv over this as per International Commission on Radiological Protection
  • Lethal dose
    • LD 50/60 is the lethal dose at which 50% of the population die within 60 days of exposure = 3.5-4.5 Gy (350-450 rad)
    • With supportive medical therapy can rise to 4.8-5.4 Gy
    • With stem cell therapy and haematopoietic growth factor administration, theoretically risen to 11 Gy

Clinical Effects of Radiation

  • Local radiation injury
    • Usually partial-body exposure causing dose-dependent cutaneous involvement
    • Week 1 – Transient erythema, hyperaesthesia and itching
    • Week 2 – Erythema with hair loss
    • Week 3 – Skin tenderness, swelling and pruritis
    • Week 4 – Dry (10-15 Gy) or wet (15-20 Gy) desquamation (and/or ulceration (>25Gy)
    • If >50Gy, will present similarly to thermal burns and onset of pain will be immediate

Acute radiation syndrome

  • Should be expected in which whole body gamma dose exceeds 2 Gy
  • Internal contamination of alpha or beta particles could also cause this
  • Neutron sources are rare but could lead to this
  • Four phases:
    • Prodrome – Transient autonomic response directly related to dose
      • High doses cause acute severe symptoms
      • Low dose cause prolonged onset and milder symptoms
      • Nausea, vomiting, anorexia, diarrhoea, hypotension, pyrexia, diaphoresis, cephalgia and fatigue
    • Latent phase – Symptom-free interval. Larger doses have shorter latent
      • 4Gy 1-3 weeks vs. >15Gy only hours
    • Manifest-illness phase
      • Three dose-dependent syndromes hallmarked by affected organ system
      • Haematopoietic, GI and Cardiovascular/CNS
    • Recovery
  • Haematopoietic syndrome
    • Seen if doses >1.5 Gy
    • Latent phase 1-3 weeks
    • Destroys bone marrow stem cells and circulating cells (esp. lymphocytes)
    • Peripheral lymphocyte count is best marker
    • Morbidity and mortality depend on associated pancytopaenia, immunosuppression and haemorrhage
    • Blood products and GF may increase survival
  • GI syndrome
    • >6Gy
    • Nausea, vomiting and diarrhoea within hours then latent phase for up to 1 week, then manifest recurrent nausea, vomiting, diarrhoea and abdo pain
    • Mucosal destruction and death of stem cells prevents regeneration and allows translocation of enteric flora into bloodstream
  • Cardiovascular/CNS
    • >20-30Gy
    • Immediate hypotension, prostration, nausea, vomiting and explosive bloody diarrhoea
    • Hypotension resistant to therapy
    • CNS within hours with seizures, lethargy, disorientation, ataxia and tremors
    • Lymphocyte count falls to zero within hours and death from circulatory collapse within 72 hours

Emergency Response Planning

  • Pre-hospital
    • Incident command, PPE, transportation of seriously ill individuals (even if contaminated) and radiation monitoring + decontamination of medically stable patients at scene
  • ED notification and preparation
    • Initiate hospital disaster plan
    • Prepare the ED: Ad hoc triage area, contaminated and clean areas, cover flooors with plastic, remove pregnant women and non-essential equipment/personnel, request extra gloves/PPE
    • Standard precautions for all staff – Double glove with inner gloves taped in place, frequent radiometer scanning of staff and dosimeters worn at collar

Triage principles

  • Radioactive contamination is never immediately life-threatening so do not delay treatment of life-threatening injuries for radiologic surveying
  • Morbidity and mortality rise significantly from ionising radiation in the setting of major trauma, thermal burns or significant medial illness

Treatment

  • Stabilise life-threatening issues
  • External exposure
    • Evalute for ARS and local radiation injury
    • Identify radionuclide
    • If persistent vomiting, consider whole body external exposure dose assessment
    • Serial FBC, amylase, CRP QID for 3 days
    • Dose assess local external exposure examining for erythema/blistering/desquamation
  • External contamination
    • Admit to controlled area
    • Remove clothing and any shrapnel and contain in lead
    • Determine radiation type (alpha, beta, gamma)
    • ID Contaminant
    • Radiation survey of body areas with docuemntation
    • Collect samples from nose/mouth
    • Decontaminate wounds, body orifices and intact skin
    • Re-survey
    • Cut and roll clothing away from face
    • Wash wounds with water
    • Cleanse intact skin and avoid scrubbing
    • Repeat washing until radiation is <2x background
    • Cover wounds with waterproof dressings
  • Internal decontamination
    • Consider if persistently high radiation survey readings and all nose/mouth contamination cases
    • Collect nasal/mouth swabs
    • ID contaminant
    • Assess intake
    • Minimise uptake and facilitate excretion
      • May warrant cathartics, whole bowel irrigation, activated charcoal or gastric lavage or radionuclide-specific decorporation agents
    • Bioassay samples (24 hr urine/faeces collection)
    • Dose assess
  • Acute radiation syndrome
    • Analgesia
      • Avoid NSAID’s as risk of GI haemorrhage if dose >5-6 Gy
    • Antiemetics + loperamide as needed
    • Biologic dosimetry uses lab analysis (rate and nadir of lymphocyte depletion) + clinical symptoms/signs to estimate absorbed dose
    • Cytogenetic analysis for chromosomal aberrations (dicentrics) is gold standard
    • Not time of onset of all symptoms, especially vomiting and diarrhoea, as crucial for biologic dosimetry
    • If vomiting and diarrhoea occur within first 2-3 hours (dose >2Gy) consider need for HLA-typing in anticipation of pancytopaenia
    • Monitor vitals, ALOC, ataxia, motor or sensory deficits, reflex abnormaliities, papilloedema, GI tenderness and GI bleeding
    • Monitor for severe infectious and metabolic complications
  • Local radiation injury
    • Analgesia
    • Traditional burn care
    • Typical steroids are helpful
    • Vitamin A, C, E and pentoxifylline (reduced blood viscosity and increases blood flow) supplementation help
    • Systemic steroids not recommended

Prenatal exposures

  • Foetus is protected by uterus and surrounding tissues
  • Alpha and beta particles unlikely to reach fetus
  • Internal contamination can expose fetus to high amounts of radiation as may accumulate in bladder of mother
  • <2 weeks = all or none
    • >0.1Gy considered lethal
  • 2-8 weeks = organogenesis
    • Neurological and motor system derangement
  • >8 weeks
    • Ongoing CNS organoegneesis with risk of mental retardation and miscarriage
    • <0.05Gy would not be expected to produce an increased risk of non-cancer health effects

Last Updated on November 23, 2021 by Andrew Crofton
