Paediatric Lower Limb Fractures

Paediatric Lower Limb Fractures

SUFE

  • Aetiology is unknown
  • Relatively common. 0.2-10 per 100 000 population
  • More common in boys (60%)
  • Mean age of diagnosis 13.5 years in boys and 12 in girls
  • 50% of adolescents with SUFE are obese
  • Bilateral in 18-50% of patients
  • Acute
    • Presents with sudden onset pain in hip and inability to walk
    • Vague pain in groin, thigh or knee
    • Knee pain is commonly the only complaint
  • Chronic
    • Antalgic gait
    • Out-toeing
    • Some shortening of affected limb
    • Obligatory external rotation during flexion of hip is a reliable sign
    • Common to see misdiagnosis of knee pain and delayed dx of SUFE
  • Ix
    • AP and frog lateral of both hips should be ordered
    • Frog lateral not performed in acute, unstable SUFE due to potential for displacement
      • Cross-table lateral X-ray can be performed
  • Rx
    • Keep non-weight-bearing
    • All need surgery and orthopaedic referral
  • Complications
    • Osteonecrosis – 50% if unstable SUFE, even if treated
    • Chondrolysis – Typically from screw/pin misplacement. 7%
    • Osteoarthritis
    • Impingement

Hip dislocation

  • Rare in children and suggests significant trauma if older child or can occur in those <5yo with minor trauma
  • Typically without fracture
  • Presentation
    • Uncomfortable, not moving leg. Leg appears shortened.
    • Anterior dislocation – Abducted and externally rotated
    • Posterior dislocation – Adducted and internally rotated with hip in flexed position
  • Ideally reduce in theatre. Rarely may need to be done in ED
  • Complications
    • AVN of femoral head
      • 3-15% risk
      • Significant risk if not reduced within 6 hours
    • Nerve injury (2-10%)
    • Femoral head overgrowth (coxa magna)
    • Osteoarthritis (acetabular fractures)
    • Recurrent dislocation
    • Growth arrest

Neck of femur fractures

  • High energy trauma and rare in children
  • Delbet classification
    • Type I: Through physis (5%)
    • Type II: Transcervical (50%)
    • Type III: Base of neck (25-30%)
    • Type IV: Intertrochanteric (15%)
  • Management
    • Reduce in theatre
  • Complications
    • AVN of femoral head: Delbet type I (100%), type II (61%), type III (27%) and type IV (14%)
    • Coxa vara: Neck-shaft ankle <120 degrees. Seen in up to 30%
    • Growth arrest: Associated with AVN and transphyseal fixation. Contributes 15% to limb length
    • Chondrolysis
    • Infection (<1%)

Femoral shaft

  • Peak in early childhood and early adolescence
  • In older children, high energy trauma in 90%
  • In younger children, due to falls
  • If under 4yo, 30% associated with NAI
  • If not yet walking, must rule out NAI
  • Rx
    • Put in skin traction (10% of body weight) + femoral nerve block
    • Thomas splint if transported
  • If hypotensive, consider alternative cause for shock

Tibial shaft

  • Direct trauma produces transverse or segmental fractures
  • Rotational forces produce spiral fracture
  • 30% associated with fibular fracture
  • Toddlers fractures
    • Occur in young ambulatory children 9 months to 3yo
    • Spiral or oblique, non-displaced distal tibial shaft fracture with intact fibula
    • Periosteum remains intact and bone is stable
    • Occur through twisting
    • May not be visible on X-ray for first week (oblique views may help)
      • May be visible at 7-10 days once periosteal reaction occurs
    • Must exclude alternate cause for limb pain (septic arthritis, osteomyelitis)

Tibial shaft – Reduction?

Parameter<8yo>8yo
AP or lateral10 degrees5 degrees
Shortening10mm5mm
Rotation10 degrees5 degrees
Apposition0%50%
  • Toddlers – No reduction. Backslab can be applied
  • Undisplaced tibial shaft – Procedural sedation for above-knee cast with knee flexed 30-40 degrees and ankle in neutral dorsiflexion
  • Displaced – Closed reduction in procedural sedation
    • If unstable, may require GA and MUA
    • Above knee cast
  • Complications
    • Compartment syndrome
      • If concerned, splint and delay casting until swelling reduced. Close clinical observation is recommended
    • Vascular injury
      • Proximal tibial shaft fractures at very high risk of vascular injury
    • Angular deformity
      • Isolated tibial fractures (with intact fibula) are at risk of tibial varus angular deformity so need close follow-up in first 3 weeks

Ankle fractures

  • Classified by Salter-Harris classification
  • Closure of the distal tibial physis occurs asymmetrically
    • Central closure first
    • Medial closure second
    • Lateral closure third
  • Results in transitional fractures
    • Tillaux fracture – Salter-Harris III fracture with avulsion of anterolateral corner of distal tibial epiphysis (last portion to close)
    • Triplane fracture – Salter-Harris IV fracture in sagittal, transverse and coronal planes

Tillaux fracture

Triplane fracture

  • Transverse through physis
  • Coronal through posterior metaphysis
  • Sagittal within epiphysis and extending to joint
  • Salter-Harris I distal fibular fractures are the most common ankle fractures and are often misdiagnosed as ankle sprains
    • Tenderness directly over lateral malleolus rather than at lateral ligaments
    • Diagnose clinically and treat as fracture (Weber B)
  • If tillaux or triplane suspected, discuss with ortho re: CT
  • Attempt to gain anatomic reduction in all cases
    • If not anatomical, d/w Ortho

Management

  • Isolated undisplaced distal fibula physeal (SH I or II)
    • No reduction required
    • Below knee cast, NWB
  • Undisplaced distal tibial physeal
    • Above knee cast, NWB
    • Discuss SH III and IV with Ortho re: CT to confirm actually not displaced
  • Displaced tibial physeal
    • Above knee cast, NWB following closed reduction
    • Ortho consult for SH III or IV
  • Tillaux and triplane <2mm displaced
    • Above knee cast, NWB and d/w Ortho re: CT to confirm truly not displaced
  • Tillaux and triplane >2mm displaced
    • Typically require operative intervention. Consult ortho

Last Updated on November 10, 2021 by Andrew Crofton
