ACEM Fellowship
Paediatric Lower Limb Fractures
SUFE
- Aetiology is unknown
- Relatively common. 0.2-10 per 100 000 population
- More common in boys (60%)
- Mean age of diagnosis 13.5 years in boys and 12 in girls
- 50% of adolescents with SUFE are obese
- Bilateral in 18-50% of patients
- Acute
- Presents with sudden onset pain in hip and inability to walk
- Vague pain in groin, thigh or knee
- Knee pain is commonly the only complaint
- Chronic
- Antalgic gait
- Out-toeing
- Some shortening of affected limb
- Obligatory external rotation during flexion of hip is a reliable sign
- Common to see misdiagnosis of knee pain and delayed dx of SUFE
- Ix
- AP and frog lateral of both hips should be ordered
- Frog lateral not performed in acute, unstable SUFE due to potential for displacement
- Cross-table lateral X-ray can be performed
- Rx
- Keep non-weight-bearing
- All need surgery and orthopaedic referral
- Complications
- Osteonecrosis – 50% if unstable SUFE, even if treated
- Chondrolysis – Typically from screw/pin misplacement. 7%
- Osteoarthritis
- Impingement
Hip dislocation
- Rare in children and suggests significant trauma if older child or can occur in those <5yo with minor trauma
- Typically without fracture
- Presentation
- Uncomfortable, not moving leg. Leg appears shortened.
- Anterior dislocation – Abducted and externally rotated
- Posterior dislocation – Adducted and internally rotated with hip in flexed position
- Ideally reduce in theatre. Rarely may need to be done in ED
- Complications
- AVN of femoral head
- 3-15% risk
- Significant risk if not reduced within 6 hours
- Nerve injury (2-10%)
- Femoral head overgrowth (coxa magna)
- Osteoarthritis (acetabular fractures)
- Recurrent dislocation
- Growth arrest
- AVN of femoral head
Neck of femur fractures
- High energy trauma and rare in children
- Delbet classification
- Type I: Through physis (5%)
- Type II: Transcervical (50%)
- Type III: Base of neck (25-30%)
- Type IV: Intertrochanteric (15%)
- Management
- Reduce in theatre
- Complications
- AVN of femoral head: Delbet type I (100%), type II (61%), type III (27%) and type IV (14%)
- Coxa vara: Neck-shaft ankle <120 degrees. Seen in up to 30%
- Growth arrest: Associated with AVN and transphyseal fixation. Contributes 15% to limb length
- Chondrolysis
- Infection (<1%)
Femoral shaft
- Peak in early childhood and early adolescence
- In older children, high energy trauma in 90%
- In younger children, due to falls
- If under 4yo, 30% associated with NAI
- If not yet walking, must rule out NAI
- Rx
- Put in skin traction (10% of body weight) + femoral nerve block
- Thomas splint if transported
- If hypotensive, consider alternative cause for shock
Tibial shaft
- Direct trauma produces transverse or segmental fractures
- Rotational forces produce spiral fracture
- 30% associated with fibular fracture
- Toddlers fractures
- Occur in young ambulatory children 9 months to 3yo
- Spiral or oblique, non-displaced distal tibial shaft fracture with intact fibula
- Periosteum remains intact and bone is stable
- Occur through twisting
- May not be visible on X-ray for first week (oblique views may help)
- May be visible at 7-10 days once periosteal reaction occurs
- Must exclude alternate cause for limb pain (septic arthritis, osteomyelitis)
Tibial shaft – Reduction?
Parameter | <8yo | >8yo |
AP or lateral | 10 degrees | 5 degrees |
Shortening | 10mm | 5mm |
Rotation | 10 degrees | 5 degrees |
Apposition | 0% | 50% |
- Toddlers – No reduction. Backslab can be applied
- Undisplaced tibial shaft – Procedural sedation for above-knee cast with knee flexed 30-40 degrees and ankle in neutral dorsiflexion
- Displaced – Closed reduction in procedural sedation
- If unstable, may require GA and MUA
- Above knee cast
- Complications
- Compartment syndrome
- If concerned, splint and delay casting until swelling reduced. Close clinical observation is recommended
- Vascular injury
- Proximal tibial shaft fractures at very high risk of vascular injury
- Angular deformity
- Isolated tibial fractures (with intact fibula) are at risk of tibial varus angular deformity so need close follow-up in first 3 weeks
- Compartment syndrome
Ankle fractures
- Classified by Salter-Harris classification
- Closure of the distal tibial physis occurs asymmetrically
- Central closure first
- Medial closure second
- Lateral closure third
- Results in transitional fractures
- Tillaux fracture – Salter-Harris III fracture with avulsion of anterolateral corner of distal tibial epiphysis (last portion to close)
- Triplane fracture – Salter-Harris IV fracture in sagittal, transverse and coronal planes
Tillaux fracture
Triplane fracture
- Transverse through physis
- Coronal through posterior metaphysis
- Sagittal within epiphysis and extending to joint
- Salter-Harris I distal fibular fractures are the most common ankle fractures and are often misdiagnosed as ankle sprains
- Tenderness directly over lateral malleolus rather than at lateral ligaments
- Diagnose clinically and treat as fracture (Weber B)
- If tillaux or triplane suspected, discuss with ortho re: CT
- Attempt to gain anatomic reduction in all cases
- If not anatomical, d/w Ortho
Management
- Isolated undisplaced distal fibula physeal (SH I or II)
- No reduction required
- Below knee cast, NWB
- Undisplaced distal tibial physeal
- Above knee cast, NWB
- Discuss SH III and IV with Ortho re: CT to confirm actually not displaced
- Displaced tibial physeal
- Above knee cast, NWB following closed reduction
- Ortho consult for SH III or IV
- Tillaux and triplane <2mm displaced
- Above knee cast, NWB and d/w Ortho re: CT to confirm truly not displaced
- Tillaux and triplane >2mm displaced
- Typically require operative intervention. Consult ortho
